Screw
Outside dia.(Min)
Thickness
Band
Rib
Designation
Basic dia screw D
No. of threads(per 25.4 mm)
Lenght of internal
Lenght of internal
Internal thread side A1
External thread side A2
t
Outside dia F
Width
No.
Basic size
Tolerance
m
h
Socket cap
1/8
9.728
28
6
8
15
9
2
1.5
18
3
5
2
1/4
13.157
19
8
11
19
12
2.5
2
22
3
5
2
3/8
16.662
19
9
12
23
14
2.5
2
26
3
5
2
1/2
20.955
14
11
15
27
18
2.5
2
30
4
6
2
3/4
26.441
14
13
17
33
24
3
2.3
36
4
6
2
1
33.249
11
15
19
41
30
3
2.3
44
5
7
2
1 1/4
41.910
11
17
22
50
39
3.5
2.8
53
5
8
2
1 1/2
47.803
11
18
22
56
44
3.5
2.8
60
5
9
2
2
59.614
11
20
26
69
56
4
3.3
73
5
11
2
2 1/2
75.184
11
23
30
86
72
4.5
3.5
91
6
12
2
3
87.884
11
25
34
99
84
5
4
105
7
13
2
4
113.030
11
28
40
127
110
6
5
133
8
16
4
5
138.430
11
30
44
154
136
6.5
5.5
161
8
18
4
6
163.830
11
33
44
182
160
7.5
6.5
189
8
20
4
